バックホウ用社外フロントアイドラーのCAT対応機種(型式)一覧

2022年11月17日
バックホウ用として販売している社外フロントアイドラー「日本キャタピラー(CAT)の対応機種」を、型式別に一覧でご紹介いたします。





●フロントアイドラー【CAT 対応機種(型式)一覧】

 <表記内容>「型式-枝番 SER:製造番号」
(鉄) → 鉄キャタ用
(ゴム) → ゴムクローラー用
(共通) → 鉄キャタ/ゴムクローラー共用

ME05 SER:E9E (ゴム)

ME08 SER:E1E (ゴム) / ME08B SER:E9B00101- (ゴム)

ME15 SER:E2E00001- (ゴム)

ME20 SER:E3E (共通)

ME25 SER:E4E (共通)

ME30 SER:E5E (共通)

ME35 SER:E6E (共通)

ME40 SER:E7E (共通)

ME45 SER:E8E (共通)

MM05 SER:E9E00425- (ゴム)

MM08B SER:E9B00765- (ゴム)

MM15 SER:E2E01295- (共通) / MM15T SER:E6G (共通)

MM20 SER:E5F (共通) / MM20CR SER:E5G (共通) / MM20SR SER:E4G (共通) / MM20T SER:E7G (共通)

MM25 SER:E4F (共通) / MM25T SER:E8G (共通)

MM30 SER:E3F (共通) / MM30B SER:E8F (共通) / MM30CR SER:E9G (共通) / MM30SR SER:E3G (共通) / MM30SR-3 SER:E8H (共通) / MM30T SER:E3H (共通)

MM35 SER:E2F (共通) / MM35B SER:E7F (共通) / MM35T SER:E4H (共通)

MM40CR SER:E1H (共通) / MM40SR SER:E2G (共通) / MM40SR-3 SER:E1J (共通) / MM40T SER:E6H (共通)

MM45 SER:E1F (共通) / MM45B SER:E6F (共通) / MM45T SER:E5H (共通)

MM55SR SER:E1G (共通)

MM57SR SER:E7H (共通)

MX15 SER:E6D

MX35 SER:E7D (鉄) / MX35 SER:E7D (ゴム)

MX45 SER:E8D (共通)

MX55 SER:E9D (鉄) / MX55 SER:E9D (ゴム)

MXR30 SER:E1D (鉄) / MXR30 SER:E1D (ゴム)

MXR35 SER:E2D (鉄) / MXR35 SER:E2D (ゴム)

MXR50 SER:E3D (鉄) / MXR50 SER:E3D (ゴム)

MXR55 SER:E4D (鉄) / MXR55 SER:E4D (ゴム)

MS010 SER:E1A (鉄) / MS010 SER:E1A (ゴム) / MS010 SER:E1C (鉄) / MS010 SER:E1C (ゴム)

MS020 SER:E2A (鉄) / MS020 SER:E2A (ゴム) / MS020 SER:E2C (鉄) / MS020 SER:E2C (ゴム)

MS030 SER:E3C (鉄) / MS030 SER:E3C (ゴム) / MS030 SER:E4A (鉄) / MS030 SER:E4A (ゴム)

MS035 SER:E4C (鉄) / MS035 SER:E4C (ゴム) / MS035 SER:E5A (鉄) / MS035 SER:E5A (ゴム)

MS03M SER:E3B

MS040 SER:E1B (鉄) / MS040 SER:E1B (ゴム) / MS040 SER:E5C (鉄) / MS040 SER:E5C (ゴム)

MS04M SER:E7A (鉄) / MS04M SER:E7A (ゴム) / MS04M SER:E8A (鉄) / MS04M SER:E8A (ゴム) / MS04M SER:E9A (鉄) / MS04M SER:E9A (ゴム)

MS070 SER:3CG (鉄) / MS070L SER:9CD (鉄) / MS070U SER:9BD

MS090 SER:3DG / MS090 SER:3EG

MS110 SER:9YD

MS120 SER:1LF

MS140 SER:1NF / MS140 SER:1PF / MS140-8 SER:000

MS160 SER:9ZD

MS1600 SER:3MG

MS160L SER:1NG

MS180 SER:2BF / MS180 SER:3LF / MS180 SER:4HF / MS180 SER:9KD

MS210 SER:1PG

MS230 SER:9LD

MS240 SER:2HF / MS240 SER:4KF/ MS240 SER:4MF

MS270 SER:1KG

MS280 SER:1KG

MS300 SER:1EG / MS300 SER:1KG / MS300 SER:4PF / MS300 SER:4SF

MS380 SER:9PD

MS450 SER:3HG

MS580 SER:9RD

MS650 SER:3LG

E110 SER:3GG / E110B SER:9HF (鉄)

E120 SER:1MF/ E120B SER:7NF (鉄)

E140 SER:1PF

E180 SER:2BF

E200B SER:4SG (鉄) / E200B SER:6KF (鉄)

E240 SER:1FG / E240 SER:2HF / E240B SER:9PF / E240C SER:8MK

E300 SER:1KG / E300B SER:2HJ

E450 SER:3JG

E650 SER:3LG

E70 SER:3CG (鉄) / E70B SER:7YF (鉄)

EL180 SER:4HF

EL200B SER:5EG (鉄) / EL200B SER:7DF (鉄)

EL240 SER:4JF / EL240 SER:4MF / EL240B SER:6MG (鉄) / EL240C SER:9NK

EL300 SER:4SF / EL300B SER:1GK

005 SER:K01-30165- (ゴム)

008CR SER:K02 (ゴム)

010CR SER:K03 (ゴム)

017CR SER:K04-13100- (鉄) / 017CR SER:K04 (ゴム)

020CR SER:K05 (共通) / 020SR SER:K06 (共通) / 020ESR SER:K06 (共通)

030SR SER:K07 (共通)

040SR SER:K08 (共通)

050SR SER:K09 (鉄) / 050SR SER:K09 (ゴム)

301.5CR SER:RAA (共通)

302CCR SER:KSG (共通) / 302CSR SER:LJF (共通)

303.5CCR SER:CRL (共通) / 303.5DCR SER:SEG (共通) / 303.5ECR SER:SFH (共通) / 303.5ECRSC SER:RSE (共通)

303CCR SER:AZS (共通) / 303CR SER:CAR (共通) / 303CR SER:DMA / 303CSR SER:MSP (共通) / 303ECR SER:SMG (共通) / 303ECRSC SER:CR7 (共通) / 303SR SER:FAD (共通)

304.5 SER:ANR

304CCR SER:ENW (共通) / 304CCR SER:FPK / 304CCR SER:STB (共通) / 304CR SER:BTN (共通) / 304CSR SER:NBM (共通) / 304ECR SER:SSC (共通) / 304ECRSC SER:TSR (共通)

305.5DCR SER:YHS (共通) / 305.5ECR SER:YGB (共通) / 305.5ECRSC SER:FSC (共通)

305CCR SER:GYZ (共通) / 305CR SER:BMW (共通) / 305CSR SER:KMC (共通) / 305DCR SER:WCJ (共通) / 305ECR SER:WDL (共通) / 305ECRSC SER:XSC (共通) / 305SR SER:DCR (共通)

307 SER:2PM/ 307 SER:9ZL (共通) / 307B SER:4RW (共通) / 307BSB SER:7DZ (共通) / 307C SER:BAJ (共通) / 307C SER:BCM (共通) / 307D SER:ECT (共通) / 307SSR SER:2FL

308BCR SER:3YS (共通) / 308BSR SER:3YS (共通) / 308CCR SER:CPE (共通) / 308CCR SER:KCX / 308CSR SER:CRW (共通) / 308DCR SER:HSA (共通) / 308DSR SER:JPS (共通) / 308E2CR SER:MY2 / 308E2CR SER:TMV / 308E2CRSC SER:EC2 / 308E2SR SER:SR8 / 308E2SRSC SER:TM2 / 308ECR SER:HEL (共通) / 308ECRSC SER:HAM (共通) / 308ECSR SER:JBE (共通) / 308ESRSC SER:JSN (共通)

311 SER:5PK (鉄) / 311 SER:5PK (ゴム) / 311 SER:5PK (鉄) / 311B SER:2MS (鉄) / 311B SER:8HR (鉄) / 311CU SER:CKE () / 311CU SER:CLK (鉄) / 311CU SER:CLK (鉄) / 311DRR SER:AKW (鉄) / 311DRR SER:AKW (鉄) / 311FRR SER:JFT (鉄)

312 SER:7DK (鉄) / 312B SER:3ES (鉄) / 312B SER:9HR (鉄) / 312C SER:CAE (鉄) / 312C SER:CAE (鉄) / 312D SER:FBJ (鉄) / 312E SER:GAC (鉄)

313BCR SER:AEX (鉄) / 313BCR SER:AEX (鉄) / 313BSR SER:9PR (鉄) / 313CCR SER:HGF (鉄) / 313CSR SER:WSA (鉄) / 313DCR SER:LCE (鉄) / 313DSR SER:LBR (鉄)

314CCR SER:KHB (鉄) / 314CCR SER:KJA / 314DCR SER:MFK (鉄) / 314ESR SER:ECN (鉄) / 314E SER:YCW (鉄) / 314EL SER:DKD / 314EL SER:ZJT

315 SER:6XM (鉄) / 315B SER:2DW (鉄) / 315C SER:BTL (鉄) / 315C SER:CFL (鉄) / 315DL SER:BYK (鉄)

316EL SER:WZY (鉄)

318CLN SER:CWP (鉄)

320 SER:3XM (鉄) / 320 SER:7GJ (鉄) / 320B SER:1CS (鉄) / 320B SER:3MR (鉄) / 320BE SER:4FS (鉄) / 320BEL SER:4EW () / 320BL SER:2WZ (鉄) / 320BL SER:4MR (鉄) / 320BLU SER:7ZZ (鉄) / 320BU SER:8GZ (鉄) / 320C SER:AKH (鉄) / 320C SER:BCB (鉄) / 320C SER:FBA (鉄) / 320C SER:MAA (鉄) / 320CL SER:ALF (鉄) / 320CL SER:BDB (鉄) / 320CL SER:GAA (鉄) / 320CL SER:PAA (鉄) / 320CLU SER:ALX (鉄) / 320CLU SER:GAB (鉄) / 320CU SER:APA (鉄) / 320CU SER:FBB (鉄) / 320D SER:AZR (鉄) / 320D SER:BWZ (鉄) / 320D SER:EBT (鉄) / 320D SER:SNS (鉄) / 320DL SER:BWP (鉄) / 320DL SER:DFB (鉄) / 320DL SER:FNA (鉄) / 320DL SER:WJN (鉄) / 320DLRR SER:CWN (鉄) / 320DLRR SER:SCW (鉄) / 320DRR SER:AMR (鉄) / 320DRR SER:RBL (鉄) / 320E SER:AWS (鉄) / 320E SER:SXE (鉄) / 320EL SER:KLT (鉄) / 320EL SER:LAK (鉄) / 320ELRR SER:MEW (鉄) / 320ERR SER:LHN (鉄) / 320L SER:4JM (鉄) / 320L SER:8HJ (鉄)

321BCR SER:AKG (鉄) / 321BLCR SER:9CZ (鉄) / 321BSR SER:4MR (鉄) / 321CCR SER:DAX (鉄) / 321CLCR SER:KBB (鉄) / 321DCR SER:JCX (鉄) / 321DLCR SER:KBH (鉄)

322 SER:7WL (鉄) / 322B SER:3NR (鉄) / 322BL SER:1AS (鉄) / 322BL SER:5CR (鉄) / 322C SER:ADX (鉄) / 322C SER:BFN (鉄) / 322C SER:BNY (鉄) / 322C SER:HBG (鉄) / 322CL SER:BFX (鉄) / 322CL SER:BMX (鉄) / 322CL SER:BTE (鉄) / 322CL SER:KCF (鉄) / 322L SER:8CL (鉄)

324D SER:AWN (鉄) / 324D SER:ECH (鉄) / 324DL SER:BYE (鉄) / 324E SER:JCZ (鉄) / 324EL SER:KTE (鉄)

325 SER:5WK (鉄) / 325 SER:8JG (鉄) / 325B SER:8GM (鉄) / 325BL SER:7EN (鉄) / 325BL SER:1GS (鉄) / 325C SER:BKH (鉄) / 325C SER:BKH (鉄) / 325C SER:BKT (鉄) / 325CL SER:BLA (鉄) / 325CL SER:BLX (鉄) / 325D SER:CJM (鉄) / 325DL SER:DAP (鉄) / 325DL SER:PEH (鉄) / 325L SER:6KK (鉄) / 325L SER:7CJ (鉄)

328DLCR SER:BYH (鉄)

329D SER:BBF (鉄) / 329DL SER:LFW (鉄) / 329DL SER:TAY (鉄) / 329E SER:PTY (鉄) / 329EL SER:RDX (鉄) / 329EL SER:WJK (鉄)

330 SER:9NG (鉄) / 330 SER:9PJ (鉄) / 330B SER:5EZ (鉄) / 330B SER:9HN (鉄) / 330BL SER:1JS / 330BL SER:2RR / 330C SER:BTM (鉄) / 330C SER:GAG (鉄) / 330CL SER:HAA (鉄) / 330CL SER:RBH (鉄) / 330D SER:KAB (鉄) / 330D SER:LCJ (鉄) / 330D SER:PCK (鉄) / 330D SER:PFC (鉄) / 330DL SER:LDR (鉄) / 330DL SER:NEF (鉄) / 330DL SER:RDA (鉄) / 330DL SER:RDK (鉄) / 330L SER:6SK (鉄) / 330L SER:6WJ (鉄)

336D SER:EMX (鉄) / 336D SER:JER (鉄) / 336DL SER:NLS (鉄) / 336DL SER:SKE (鉄) / 336E SER:CMR (鉄) / 336E SER:KED (鉄) / 336EH SER:HDW (鉄) / 336EL SER:GTJ (鉄) / 336EL SER:TEG (鉄) / 336ELH SER:JEA (鉄) / 336ELH SER:RZA (鉄) / 336ELNH SER:SSL / 336FLXE SER:DFY / 336FLXE SER:KGH / 336FLXE SER:LTP / 336FLXE SER:MTW

345B SER:6MW (鉄) / 345B SER:8KW (鉄) / 345BII SER:AMD (鉄) / 345BII SER:AMN (鉄) / 345BL SER:8RW (鉄) / 345BL SER:9CW (鉄) / 345BLII SER:AMJ (鉄) / 345BLII SER:AYR (鉄) / 345C SER:JAR (鉄) / 345C SER:MDC (鉄) / 345CL SER:GBH (鉄) / 345CL SER:RFN (鉄) / 345D SER:BYW (鉄) / 345D SER:FES (鉄) / 345DL SER:DPA (鉄) / 345DL SER:HLC (鉄)

349E SER:FJB (鉄) / 349E SER:RGH (鉄) / 349EL SER:SPG (鉄) / 349EL SER:WHZ (鉄)

350 SER:7RK (鉄) / 350L SER:9DK (鉄)

365BL SER:4XZ (鉄) / 365BLII SER:BTH (鉄) / 365CL SER:FEN (鉄)

374DL SER:PJA (鉄) / 375 SER:8XG (鉄) / 375L SER:6RL

385B SER:BKX (鉄) / 385C SER:MNZ (鉄)

390D SER:BYP (鉄)
